Outline Drawing Of CA45/14
◆ Secondary Current:5A
◆ Frequency:50-60Hz
◆ Rated Votlage:720V
◆ Security Factor:FS-5
◆ High Voltage Test:4KVeff,50Hz,1Min
◆ Weight:200-250gr
|
Rated Current(A) Primary /Secondary |
30/5A 40/5A |
50/5A |
60/5A |
75/5A 80/5A |
100/5A |
|
Accuracy Class |
3 |
1.0 |
1.0 |
1.0 |
1.0 |
|
Rated Burden(VA) |
1 |
1.5 |
2.5 |
2.5 |
25 |
Outline Drawing Of CA62/WS
|
Mode |
Rated Current (VA) |
Rated Burden (VA) |
Accuracy Class |
Rated Voltage Rated Frequency (V) (Hz) |
|
CA62/WS |
5/5A-80/5A |
5VA |
0.5 720 50/60 |
|
|
5/0.05A-5/5A |
1-5VA |
0.5 720 50/60 |
||
CA62/30-CA104/80 Technical date
|
Secondary Current:5A |
|
Frequency:50-60Hz |
|
Rated Votlage:720V |
|
Security Factor:FS-5 |
|
High Voltage Test:4KVef,50Hz,1Min |
|
Weight:200-250gr |
CA Current Transformers
Outline Drawing Of CA62/30-CA104/80
|
Unit:mm |
||||||||||||||
|
Model CA62/20 |
A 78 |
B 36 |
C 6.6 |
D 36 |
E 55 |
F 71 |
G |
H |
J |
K |
L 21 |
M |
O |
P |
|
CA62/30 |
78 |
47 |
6.6 |
35 |
55 |
71 |
30.5 |
11 |
11 26 |
44 |
31 |
62 |
21 |
26 |
|
CA62/40 |
78 |
47 |
6.6 |
35 |
55 |
71 |
31 |
11 |
16 31 |
44 |
41 |
62 |
21 |
26 |
|
CA74/40 |
98 |
61 |
6.6 |
45 |
67 |
81 |
33 |
11 |
11 31 |
47 |
41 |
74 |
21 |
31 |
|
CA74/50 |
98 |
61 |
6.6 |
45 |
67 |
81 |
41 |
12 |
31 41 |
47 |
51 |
74 |
21 |
31 |
|
CA86/60 |
110 |
56 |
6.6 |
40 |
62 |
76 |
51 |
12 |
21 51 |
68 |
61 |
86 |
31 |
44 |
|
CA104/80 |
126 |
56 |
6.6 |
40 |
62 |
76 |
65 |
12 |
31 61 |
86 |
81 |
104 |
31 |
56 |
Outline Drawing Of CA145/100
Rated Current (A)
Primary/Secondary Current: 1000/5A-3200/5A
Rated Burden: 15VA-60VA
Accuracy Class: 1.0-0.2
Operating Frequency: 50-60Hz
